Q2V-A4007-BAA Omron

Q2V-A4007-BAA

Нет в наличии

Уточнить цену

Q2V-A4007-BAA

Уточнить цену

Q2V - Driving Quality Спецификация

enPDF 1,3 МБ

Нет в наличии

Уточнить цену

Описание

Drive control method	Open loop V/f, Open loop vector
Drive supply voltage	400 V three phase
Max. motor output at constant torque (HD)	2.2 kW
Max. motor output at variable torque (ND)	3.0 kW
Built in EMC filter
Degree of protection (IP)	IP20
Finless type
Compatible motor type	Induction or asynchronous motor, Permanent magnet motor, Synchronous reluctance motor
Regenerative solutions	As inverter option
Communication port(s)	MODBUS Slave, Serial RS-485, USB
Communication option(s)	Bluetooth, CANopen, DeviceNet Slave, EtherCAT Slave, EtherNet/IP, POWERLINK, PROFIBUS DP Slave, PROFINET Slave
Height	128 mm
Width	108 mm
Depth	154 mm
Weight	1500 g
