G3H-203S-VD 4-24VDC Omron

G3H-203S-VD 4-24VDC

Нет в наличии

Уточнить цену

G3H-203S-VD 4-24VDC

Уточнить цену

Твердотельное реле, 5-24 VDC

Нет в наличии

Уточнить цену

Описание

Application	Interface
Number of phases	1
Mounting method	With plug-in socket
Terminal	Plug-in
Complete with socket
With LED indicator
Rated operational voltage, AC	100-240 V
Operating voltage range, AC	75-264 V
Rated operation current Ie at AC-1	3 A
Height	28 mm
Width	21.5 mm
Depth	36.5 mm
Supply voltage DC	4-24 V
Must operate voltage max.	3 V
Must release voltage min.	1 V
Maximum operating temperature	80 °C
Minimum operating temperature	-30 °C
Isolation	Photocoupler
Switching at zero-crossing
